SYSTEM OVERVIEW
Voltage compatibility 120 VAC
Frequency compatibility 50/60 Hz
OUTPUT
Output volt amp capacity (amps) 15
Output watts 1800
Outlet quantity / type 8 NEMA 5-15R
Outlet orientation Single row of 5, plus a second row of 3 for transformer accommodation
Outlet safety covers Includes built-in sliding outlet safety covers
Transformer accommodation Supports 3 large transformer plug accessories without covering remaining outlets, accepts up to 6 transformers total
INPUT
Input connection type NEMA 5-15P
Input cord gauge, type 14 gauge, SJT
Input cord length (ft.) 10 ft.
Input cord length (m) 3.0
Recommended Electrical Service 120V (110-125V)
Input plug features Space-saving right-angle input plug
LEDS ALARMS & SWITCHES
Diagnostic LEDs Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
Alarms Audible alarm sounds to indicate damage to suppression components
Switches Combination AC circuit breaker and 2-position red illuminated on/off power switch
SURGE / NOISE SUPPRESSION
Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
AC suppression joule rating 3690 joules
Clamping voltage (RMS) 150V
AC suppression response time < 1 ns
UL1499 let through rating 330V - UL Verified
EMI / RFI filtering Up to 40 dB
DATALINE SURGE SUPPRESSION
Telephone/DSL Protection Yes
Telephone/DSL Protection Details 2 line
Cable (Coax) Protection Yes
Cable (Coax) Protection Details 1 line (supports 2.2 GHz bandwidths)
Network (Ethernet) Protection Yes
PHYSICAL
Shipping weight (lbs) 2.8
Shipping weight (kg) 1.3
Shipping Dimensions (HWD/in) 2.5 x 14.75 x 8.75
Shipping Dimensions (HWD/cm) 6.4 x 37.5 x 22.2
Unit weight (lbs) 2
Unit weight (kg) 0.9
Unit Dimensions (HWD/in) 1.6 x 9.25 x 4.25
Unit Dimensions (HWD/cm) 4.1 x 23.5 x 10.8
Material of construction Plastic
Integrated keyhole mounting tabs Keyhole mounting tabs enable wall mounting
AC line cord color Black
Style Strip
CERTIFICATIONS
UL1449 1998 Rev. (AC Suppression) UL1449
UL1363 (Power Tap) UL1363
UL497A (Communications) UL497A
FCC Part 68 (Communications) FCC Part 68
cUL / CSA (Canada) cUL
Industry Canada (Communications) Industry Canada
Approvals Exceeds IEEE 587 category A&B specifications
